NRT-316P

The NRT-316P is a premium pedestal urinal designed for modern restroom environments. Made from high-grade ceramic, it features a robust pedestal base for added stability and support. The unit combines durability with a sleek, contemporary design, making it suitable for high-traffic commercial settings. With its smooth surface for easy cleaning and efficient flushing system, the NRT-316P ensures optimal hygiene and water-saving performance. A reliable and stylish choice for any professional washroom installation.

Dimensions

  • Overall Width: 98.5”
  • Overall Width Set-Up: 119.5″
  • Overall Length: 254”
  • Overall Height: 131.5”
  • Box Width: 76.5”
  • Box Length: 192”
  • Interior Height: 82.5”
  • Curb Weight: 4820 lbs
  • Tongue Weight: 840 lbs
  • Fresh Tank Capacity: 150 gal.
  • Holding Tank Capacity: 530 gal.

Interior/Exterior Features

Interior Standard Features

  • Smooth durable fiberglass interior on composite backer (no wood)
  • 12 Volt LED lighting – (2) lights per room
  • Lockable base cabinets
  • Solid surface countertops with molded sinks
  • Waste basket cut outs and waste baskets
  • Self closing commercial faucet
  • Soap dispenser
  • Paper towel dispenser
  • Toilet paper holder
  • Ultra low water use ceramic bowl pedal flush toilet
  • Sanitary Napkin receptacles (women’s restrooms only)
  • Shatterproof mirror
  • Heavy duty door closer
  • 1 Piece transit grade flooring on non-absorbent “Ever Floor”
  • Climate control sensor inside restroom

Exterior Standard Features

  • Large 32″ heavy duty entrance doors
  • Occupancy lighting
  • 1 Piece roof
  • Smooth durable fiberglass exterior on composite backer
  • Porch light at entry door w/ switch in control room
  • Fold down steps with swing-out grab handles
  • 3″ quick connect waste tank access valve
  • LED waste tank indicator
  • 1/2″ Co-Poly waste tanks
  • Large access door in rear for 1″ wash out plug
  • City water connection
  • 30 amp marine-style power cord
  • Roof mounted Air Conditioner w/ heat strip
  • Torsion axle
  • Alum wheels with E-rated trailer specific tires nitro-filled
  • Full license plate frame with light & screws
  • Fresh water fill/diverter (either hydrates the unit or fills the fresh tank)
  • Courtesy light above Control Room door
  • Powder coated aluminum trim
  • 7k tongue jack
  • Stabilizer jacks on all (4) corners – scissor jacks on the front and swing downs on the rear
