NRT-420

The NRT-420 is a wall-mounted urinal designed for maximum efficiency and modern appeal. Constructed from high-quality ceramic, it features a streamlined design that complements contemporary restroom aesthetics. Ideal for commercial and public washrooms, the NRT-420 offers excellent durability, easy maintenance, and an efficient flushing system that promotes water conservation. Its ergonomic shape ensures user comfort while maintaining high hygiene standards.

Dimensions

  • Box Width: 76.5”
  • Overall Width: 98.5″
  • Box Length: 240”
  • Overall Length: 298″
  • Interior Height: 82.5”
  • Overall Height: 131.5″
  • Curb Weight: 5520 lbs
  • Tongue Weight: 1200 lbs
  • Fresh Tank Capacity: 150 gal.
  • Holding Tank Capacity: 720 gal.

Interior/Exterior Features

Interior Standard Features

  • Smooth durable fiberglass interior on composite backer (no wood)
  • 12 Volt LED lighting – (2) lights per room
  • Lockable base cabinets
  • Solid surface countertops with molded sinks
  • Waste basket cut outs and waste baskets
  • Self closing commercial faucet
  • Soap dispenser(shipped loose)
  • Paper towel dispenser
  • Toilet paper holder
  • Ultra low water use ceramic bowl pedal flush toilet
  • Waterfree urinal (men’s restroom only)
  • Sanitary Napkin receptacles (women’s restrooms only)
  • Shatterproof mirror
  • Heavy duty door closer
  • 1 Piece transit grade flooring on non-absorbent “Ever Floor”
  • Climate control sensor inside restroom

Exterior Standard Features

  • Large 32″ heavy duty entrance doors
  • Occupancy lighting
  • 1 Piece roof
  • Smooth durable fiberglass exterior on composite backer
  • Porch light at entry door w/ switch in control room
  • Fold down steps with swing-out grab handles
  • 3″ quick connect waste tank access valve
  • LED waste tank indicator
  • 1/2″ Co-Poly waste tanks
  • Large access door in rear for 1″ wash out plug
  • City water connection
  • 30 amp marine-style power cord
  • Roof mounted Air Conditioner w/ heat strip
  • Climate control center mounted in control room
  • External Spray Port with 30′ hose and nozzle
  • Insulated walls and ceiling
  • Torsion axle Alum wheels with E-rated trailer specific tires nitro-filled
  • Matching alum wheel spare tire & wheel mounted on tongue
  • Full license plate frame with light & screws
  • Fresh water fill/diverter (either hydrates the unit or fills the fresh tank)
  • Courtesy light above Control Room door
  • Powder coated aluminum trim
  • 7k tongue jack
  • Stabilizer jacks on all (4) corners – scissor jacks on the front and swing downs on the rear
